Display Different LED Sequences Using the MAXQ2000
Microcontroller with the MAX6970 LED Driver
By: Kien Mach
Mar 23, 2009
Abstract: This note shows an application circuit and provides all the firmware required to interface the MAXQ2000
microcontroller evaluation (EV) kit to the MAX6970, an 8-port, 36V constant-current LED driver. Included in this
application note are schematics and microcontroller firmware. The example C program was written and assembled for
the MAXQ® microcontroller with the IAR Embedded Workbench®.
Overview
The MAX6970 is an 8-port, 36V constant-current LED driver that uses a 4-wire serial interface. Using this application
note, the MAX6970 can be used with the MAXQ2000 16-bit RISC microcontroller to create a variety of simple LED
sequences with the touch of a button.
Hardware Setup
The circuit discussed in this application note utilizes the MAX6970EVKIT and the MAXQ2000-KIT. The MAX6970
evaluation (EV) kit schematic is shown in Figure 1. A MAXQ2000 EV kit board is included in the MAX6970 EV kit
design. However for this application, it will be detached from the on-board MAXQ2000, since the MAXQ2000 EV kit
has pushbutton features that would otherwise be used to control the LED sequences.
