User's Guide
SNOA535B–October 2008–Revised May 2013
AN-1906 LMH6518 Evaluation Board
1 Package Includes
• LMH6518 evaluation board (tested board that takes a 5 V and ground power supply connection and
outputs main and auxiliary differential outputs).
• USB Interface board (Figure 1) with 10 pin interconnect cable (to mate with J6 on LMH6518 evaluation
board). This board interfaces to a PC USB port to “Write” the SPI interface signals to the LMH6518
and can also display the LMH6518 state through “Read” back.
• USB Cable
Figure 1. USB Interface Board
