User's Guide
SNOA468C–June 2006–Revised May 2013
AN-1461 LMH6321 (PSOP and TO-263) Single Open Loop
High-Speed Buffer Evaluation Boards
1 General Description
The LMH6321MR-EVAL (for the 8-pin PSOP type package) and the LMH6321TS-EVAL (for the 7-pin
TO263 type package) evaluation boards are designed to aid in the characterization of Texas Instruments
high speed high current buffers. Use the evaluation boards as a guide for high frequency layout and as a
tool to aid in device testing and characterization. Both boards have identical circuit configurations and are
designed for either inverting or non-inverting gain.
The evaluation board schematic is shown in Figure 1. The schematic shows some of the components with
the recommended values. Use all surface-mount components.
All trademarks are the property of their respective owners.
