User's Guide
SNVA210B–January 2007–Revised April 2013
AN-1570 LM5576 Evaluation Board
1 Introduction
The LM5576 evaluation board is designed to provide the design engineer with a fully functional power
converter based on emulated current mode control to evaluate the LM5576 regulator IC. The evaluation
board provides a 5V output with a 3A current capability. The ultra-wide input voltage ranges from 7V to
75V. The design operates at 300kHz, a good compromise between conversion efficiency and solution
size. The printed circuit board consists of 2 layers of 2 ounce copper on FR4 material with a thickness of
0.06 inches. This application note contains the evaluation board schematic, Bill-of-Materials (BOM) and a
quick setup procedure. Refer to the LM25576/LM25576Q SIMPLE SWITCHER® 42V, 3A Step-Down
Switching Regulator (SNVS470) data sheet for complete circuit design information.
The performance of the evaluation board is as follows:
Input Range: 7 to 75V
Output Voltage: 5V
Output Current: 0 to 3A
Frequency of Operation: 300 KHz
Board Size: 2.75 X 1 X 0.4 inches
Load Regulation: 1%
Line Regulation: 0.1%
Over Current Limiting
All trademarks are the property of their respective owners.
