September 2006 Rev 1 1/32
UM0285
User guide
EK3LV02DL
Evaluation Kit
Introduction
The EK3LV02DL is an Evaluation Kit designed to provide to the user a complete, ready-to-
use platform for the evaluation of the LIS3LV02DL, a low-power 3-Axis linear accelerometer
with digital output that includes a sensing element and an IC interface able to take
information from the sensing element and to provide the measured signal to the external
world.
Besides the MEMS sensor, the evaluation board mounts an ST7-USB microcontroller which
acts like a bridge between the sensor and the personal computer on which it is possible to
run either a Graphical User Interface delivered with the kit itself or dedicated SW routines
that implements customized applications.
This user manual describes the HW composing the evaluation kit and gives the informations
required to install and to run the evaluation kit user interface.
For any
detail about the features implemented by the LIS3LV02DL sensor refer to
LIS3LV02DL datasheet and to the Application Note AN2381
