Multipurpose Two-Phase Buck PWM Controller with
Integrated MOSFET Drivers
ISL6567
The ISL6567 two-phase synchronous buck PWM control IC
provides a precision voltage regulation system for point-of-load
and other high-current applications requiring an efficient and
compact implementation. Multi-phase power conversion is a
marked departure from single phase converter configurations
employed to satisfy the increasing current demands of various
electronic circuits. By distributing the power and load current,
implementation of multi-phase converters utilize smaller and
lower cost transistors with fewer input and output capacitors.
These reductions accrue from the higher effective conversion
frequency with higher frequency ripple current resulting from
the phase interleaving inherent to this topology.
Outstanding features of this controller IC include an internal
0.6V reference with a system regulation accuracy of ±0.6%, an
optional external reference input, and user-adjustable
switching frequency. Precision regulation is further enhanced
by the available unity-gain differential amplifier targeted at
remote voltage sensing capability, while output regulation is
monitored and its quality is reported via a PGOOD pin. Also
included is an internal shunt regulator with optional external
connection capability which extends the operational input
voltage range. For applications requiring voltage tracking or
sequencing, the ISL6567 offers a host of possibilities,
including coincidental, ratiometric, or offset tracking, as well
as sequential start-ups, user adjustable for a wide range of
applications.
Protection features of this controller IC include overvoltage
and overcurrent protection. Overvoltage results in the
converter turning the lower MOSFETs ON to clamp the rising
output voltage. The ISL6567 uses cost and space-saving
r
DS(ON)
sensing for channel current balance, dynamic voltage
positioning, and overcurrent protection. Channel current
balancing is automatic and accurate with the integrated
current-balance control system. Overcurrent protection can be
tailored to various application with no need for additional
parts.
Features
• Integrated Two-Phase Power Conversion
- Integrated 4A Drivers for High Efficiency
• Shunt Regulator for Wide Input Power Conversion
- 5V and Higher Bias
- Up to 20V Power-Down-Conversion
• Precision Channel Current Sharing
- Loss-Less Current Sampling - Uses r
DS(ON)
• Precision Output Voltage Regulation
- ±0.6% System Accuracy Over-Temperature (Commercial
Range)
• 0.6V Internal Reference
• Full Spectrum Voltage Tracking
- Coincidental, Ratiometric, or Offset
• Sequential Start-up Control
• Adjustable Switching Frequency
- 150kHz to 1.5MHz
• Fast Transient Recovery Time
• Unity-Gain Differential Amplifier
- Increased Voltage Sensing Accuracy
• Overcurrent Protection
• Overvoltage Protection
• Start-up into Pre-Charged Output
• Small, QFN Package Footprint
• Pb-Free (RoHS Compliant)
Ordering Information
PART NUMBER
(Notes 1, 2, 3)
PART
MARKING
TEMP.
RANGE
(°C)
PACKAGE
(Pb-Free)
PKG.
DWG. #
ISL6567CRZ 65 67CRZ 0 to +70 24 Ld 4x4 QFN L24.4x4C
ISL6567IRZ 65 67IRZ -40 to +85 24 Ld 4x4 QFN L24.4x4C
NOTE:
1. Add “-T*” suffix for tape and reel. Please refer to TB347
for details
on reel specifications.
2. These Intersil Pb-free plastic packaged products employ special
Pb-free material sets, molding compounds/die attach materials,
and 100% matte tin plate plus anneal (e3 termination finish, which
is RoHS compliant and compatible with both SnPb and Pb-free
soldering operations). Intersil Pb-free products are MSL classified
at Pb-free peak reflow temperatures that meet or exceed the Pb-
free requirements of IPC/JEDEC J STD-020.
3. For Moisture Sensitivity Level (MSL), please see device information
page for ISL6567
. For more information on MSL please see
techbrief TB363
.
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774
|Copyright Intersil Americas Inc. 2005-2009, 2011. All Rights Reserved
Intersil (and design) is a trademark owned by Intersil Corporation or one of its subsidiaries.
All other trademarks mentioned are the property of their respective owners.
August 9, 2011
FN9243.4
