ISL6251EVAL2Z Evaluation Board
Setup Procedure
Low Cost Multi-Chemistry Battery
Charger Controller
The ISL6251, ISL6251A is a highly integrated battery
charger controller for Li-Ion/Li-Ion polymer batteries and
NiMH batteries. High Efficiency is achieved by a
synchronous buck topology and the use of a MOSFET,
instead of a diode, for selecting power from the adapter or
battery. The low side MOSFET emulates a diode at light
loads to improve the light load efficiency and prevent system
bus boosting.
The constant output voltage can be selected for 2, 3 and 4
series Li-Ion cells with 0.5% accuracy over-temperature. It
can be also programmed between 4.2V + 5%/cell and
4.2V - 5%/cell to optimize battery capacity. When supplying
the load and battery charger simultaneously, the input
current limit for the AC adapter is programmable to within
3% accuracy to avoid overloading the AC adapter, and to
allow the system to make efficient use of available adapter
power for charging. It also has a wide range of
programmable charging current. The ISL6251, ISL6251A
provides outputs that are used to monitor the current drawn
from the AC adapter, and monitor for the presence of an AC
adapter. The ISL6251, ISL6251A automatically transitions
from regulating current mode to regulating voltage mode.
Features
• ±0.5% Charge Voltage Accuracy (-10°C to +100°C)
• ±3% Accurate Input Current Limit
• ±3% Accurate Battery Charge Current Limit
• ±25% Accurate Battery Trickle Charge Current Limit
(ISL6251A)
• Programmable Charge Current Limit, Adapter Current
Limit and Charge Voltage
• Fixed 300kHz PWM Synchronous Buck Controller with
Diode Emulation at Light Load
• Output for Current Drawn from AC Adapter
• AC Adapter Present Indicator
• Fast Input Current Limit Response
• Input Voltage Range 7V to 25V
• Support 2, 3 and 4 Cells Battery Pack
• Up to 17.64V Battery-Voltage Set Point
• Thermal Shutdown
• Support Pulse Charging
• Less than 10µA Battery Leakage Current
• Charge Any Battery Chemistry: Li-Ion, NiCd, NiMH, etc.
• Pb-Free Plus Anneal Available (RoHS Compliant)
Applications
• Notebook, Desknote and Sub-notebook Computers
• Personal Digital Assistant
Ordering Information
PART
NUMBER
(Notes 1, 2)
PART
MARKING
TEMP
RANGE
(°C)
PACKAGE
(Pb-Free)
PKG.
DWG. #
ISL6251HRZ ISL 6251HRZ -10 to +100 28 Ld 5x5 QFN L28.5×5
ISL6251HAZ ISL 6251HAZ -10 to +100 24 Ld QSOP M24.15
ISL6251AHRZ ISL6251 AHRZ -10 to +100 28 Ld 5x5 QFN L28.5×5
ISL6251AHAZ ISL6251 AHAZ -10 to +100 24 Ld QSOP M24.15
NOTES:
1. Intersil Pb-free plus anneal products employ special Pb-free
material sets; molding compounds/die attach materials and 100%
matte tin plate termination finish, which are RoHS compliant and
compatible with both SnPb and Pb-free soldering operations.
Intersil Pb-free products are MSL classified at Pb-free peak reflow
temperatures that meet or exceed the Pb-free requirements of
IPC/JEDEC J STD-020.
2. Add “-T” for Tape and Reel.
AN1293.0
April 10, 2007
Application Note
