ISL36411 Evaluation Board User Guide
Description
The ISL36411DRZ-EVALZ evaluation board is a versatile
stand-alone printed circuit board developed to evaluate the
performance of the Intersil ISL36411
11.1Gb/s quad lane
extender.
Items provided with board:
•This application note
•Power cable
•Four jumpers
Key Features
• ISL36411 IC
• Connection to external 3.3V power supply
• On-board voltage regulator that provides the 1.2V supply to the
IC
• On-board boost selection using provided jumpers
• SMA connectors to access differential inputs and outputs
References
• ISL36411 Datasheet
Ordering Information
PART NUMBER DESCRIPTION
ISL36411DRZ-EVALZ ISL36411 evaluation board (power cable
and four jumpers included)
FIGURE 1. TOP OF BOARD FIGURE 2. BOTTOM OF BOARD
June 22, 2016
AN1573.1
Application Note 1573
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
