G2RL-24-CF-DC24 产品设计参考

页码:/1页

下载 PDF

重新加载

下载

Produkt Informationen

SD 1000

Bestellnummer : T0051301799

Solder dispenser

SD 1000 Solder dispenser

- For use of coils up to 1000g

- Length 95 mm, core ∅ > 17 mm

- Length 70 mm, core ∅ > 12 mm

- Length 84 mm, core ∅ < 12 mm

SD 1000 Solder dispenser

- For use of coils up to 1000g

- Length 95 mm, core ? > 17 mm

- Length 70 mm, core ? > 12 mm

- Length 84 mm, core ? < 12 mm

page 1 / 1
