SCOPE
This reference manual provides a description of the ADF7030-1
radio functionality, hardware features, and application circuit
requirements. It is intended as a resource for a hardware engineer
designing a printed circuit board (PCB) that includes the
ADF7030-1.
ABOUT THE ADF7030-1
The ADF7030-1 is a low power, high performance, fully
integrated radio transceiver that supports a wide range of
modulation scheme and channel widths in the sub GHz
frequency range.
The ADF7030-1 features an on-chip ARM® Cortex®-M0
processor that performs radio control and radio packet
management.
OTHER RELEVANT DOCUMENTATION
Complete specifications for the ADF7030-1 device can be found
in the ADF7030-1 data sheet. The ADF7030-1software reference
manual is the programming guide for the ADF7030-1 and is
available from Analog Devices, Inc. Both the ADF7030-1 data
sheet and software reference manual documents should be
consulted in conjunction with this hardware reference manual.
