DS90UR908Q-EVK
FPD-Link II to FPD-Link Converter
Evaluation Kit
Rev 0.1
May, 2010
General Description
The DS90UR908Q-EVK converts FPD-link II to FPD-Link. It translates a high-speed serialized interface with an embedded
clock over a single pair to four LVDS data/control streams and one LVDS clock pair. It is backward compatible for operation
with older generation deserializer devices.
The DS90UR908Q-EVK board has a space saving 20-position wall header as the FPD-Link output, and a Rosenberger
Automotive HSD Connector as the input. USB or SMA connectors can also be configured as the input, based on the type of
the cable to be used.
Features
• 5 – 65 MHz support (140 Mbps to 1.82 Gbps Serial Link)
• 5-channel (4 data + 1 clock) FPD-Link driver outputs
• AC Coupled STP Interconnect up to 10 meters in length
• Integrated input termination
• @ Speed link BIST Mode and reporting pin
• Optional I2C compatible Serial Control Bus
• RGB888 + VS, HS, DE converted from 1 pair
• Power down mode minimizes power dissipation
• FAST random data lock; no reference clock required
• Adjustable input receive equalization
• LOCK (real time link status) reporting pin
• Low EMI FPD-Link output
• SSCG option for lower EMI
• 1.8V or 3.3V compatible I/O interface
• Automotive grade product: AEC-Q100 Grade 2 qualified
• >8kV HBM ESD tolerance
• Backward compatible mode for operation with older generation devices
Applications
• Automotive Displays for Navigation
• Automotive Display for Entertainment
Ordering Information
PART: DS90UR908QSQ
Demo board: DS90UR908Q-EVK
