AWG#
Ins. Dia.
Pcs/Reel
20-22
Max. Ø1.7
8,000
22-28
Max. Ø1.6
8,000
AWG#
Ins. Dia. Pcs/Reel
20-22
Max. Ø1.7 8,000
Housing 22-28
Max. Ø1.6 10,000
Contact
Housing
Contact
Wire O.D.
Color
565-290-711
565-290-721
Ø1.00 to
Ø1.30
PCB Thickness
565-290-731
565-290-741
Yellow
Ø1.30 to
Ø1.70
Orange
Crimp &
Poke
Applicable Contact
Part No
565-290-741
565-290-721
1.6mm
565-200-100
PBT with Glass, UL 94V-0
15 mΩ
max
-40°C to +105°C
PBT, UL 94V-0
Part No.
Insulation Resistance
Temperature Range
1000 MΩ min./DC500V
Phosphor Bronze
Contact Plating Tin Plating
Brass
Wire & Housing Seals Silicone Rubber
PCB
Header
Waterproofing Cap PBT, UL 94V-0
Male Contact (Pin)
Female Contact (Socket)
Pitch
250V
2.5mm
Withstanding Voltage
Rated Voltage
Part No
565-290-731
565-290-711
No. of Positions 2, 3, 5P
Rated Current
1000V AC (rms)
3A max
Contact Resistance
SERIES 560
Ordering Code:
www.edac.net
Waterproofing Cap:
Wire to Wire / Wire to Board 2.5mm Pitch
• 2.5mm Pitch, Rated Current: 3A max
• Fully Waterproof with Double Latch Solution
• Available in Wire-to-Wire and Wire-to-Board Options
• Seals Preassembled into Housing; No External Sealing
Required available in 2, 3, or 5 Positions
• True Crimp and Poke Solution
• Waterproofing Cap available to cover holes of wire seal
• Internal Polarization to Prevent Mismating
• Available with wire already installed
• Waterproof Grade IP67 Certified
Specifications:
Crimp Contact:
**Crimp Contacts are also available in strips of 60pcs.
Contact EDAC for more information.
Rear Gasket (Wire Seal):
NO. OF CONTACTS:
002 - 2 CONTACTS
003 - 3 CONTACTS
005 - 5 CONTACTS
CONTACT CODE:
000 - NO CONTACTS (ONLY FOR CRIMP CONTACTS)
420 - BOARD MOUNT CONTACTS
STYLE:
101 - WHITE MALE HOUSING (ONLY FOR BOARD MOUNT CONTACTS)
301 - BLUE MALE HOUSING (ONLY FOR BOARD MOUNT CONTACTS)
110 - WHITE MALE HOUSING FOR WIRE INSULATION Ø1.00 TO Ø1.30
310 - BLUE MALE HOUSING FOR WIRE INSULATION Ø1.00 TO Ø1.30
111 - WHITE MALE HOUSING FOR WIRE INSULATION Ø1.30 TO Ø1.70
311 - BLUE MALE HOUSING FOR WIRE INSULATION Ø1.30 TO Ø1.70
210 - WHITE FEMALE HOUSING FOR WIRE INSULATION Ø1.00 TO Ø1.30
410 - BLUE FEMALE HOUSING FOR WIRE INSULATION Ø1.00 TO Ø1.30
211 - WHITE FEMALE HOUSING FOR WIRE INSULATION Ø1.30 TO Ø1.70
411 - BLUE FEMALE HOUSING FOR WIRE INSULATION Ø1.30 TO Ø1.70
560-002-000-110
SERIES:
560, WIRE TO WIRE
WIRE TO BOARD
Assembly Layout
Materials:
Double Latch
28.40
20.85
**Wire seals, housing seals and retainers are already
pre-assembled in the connector.
