User's Guide
SBAU160–October 2009
DAC8234EVM
DAC8234EVM
This user's guide describes the characteristics, operation, and use of the DAC8234EVM. The evaluation
module (EVM) is an evaluation board that allows for quick and easy evaluation of the DAC8234. The
DAC8234 is a quad, high-accuracy, 14-bit, R-2-R digital-to-analog converter (DAC). The device features
low-power operation, good linearity, and the ability to use different reference voltages for the output
channels. This EVM allows evaluation of all aspects of the DAC8234. Complete circuit descriptions,
schematic diagrams, and bill of material are included in this document.
The following related documents are available through the Texas Instruments web site at
http://www.ti.com.
EVM-Compatible Device Data Sheets
Device Literature Number
DAC8234 SBAS464
REF5025 SBOS410
REF5050 SBOS410
OPA211 SBOS377
TL750L08 SLVS017
