ATADAPCAN01 - STK501 CAN Extension
The ATADAPCAN01 - STK501 CAN add-on is an extension to the STK500 and
STK501 development boards from Atmel Corporation, adding support for the AVR
AT90CAN128 device in a single development environment.
The AVR AT90CAN128 includes a built-in Controller Area Network (CAN) controller
with all the features required to implement the CAN serial communication protocol in
accordance with the “BOSCH GmbH” CAN specification.
The add-on board provides CAN transceivers, termination options and other features
necessary to seamlessly connect the STK500 development environment to a CAN
bus for application development and debugging.
Requirements
• STK500 starter kit, serial cable and power supply
• STK501 topmodule to STK500
• AVR AT90CAN128 in 64-pin TQFP package
Rev. 4330B-CAN–03/04
CAN
Microcontrollers
Quick Start
Guide
