AVR2023 - AT86RF231 PCB reference design
for antenna diversity
Features
• 802.15.4 compliant 2.4 GHz transceiver
• Hardware supported antenna diversity
• 1.8 V to 3.6 V operation
• Low current consumption
- Typ. 600 nA (Sleep)
- Typ. 8 mA (TRX_OFF)
- Typ. 22 mA (TX, output power +3 dBm)
1 Introduction
The AT86RF231 diversity board demonstrates the capabilities of the 802.15.4
compliant 2.4 GHz radio transceiver AT86RF231. With the high performance
ATmega1281V AVR microcontroller it serves as a full function network node that is
capable of hosting a MAC implementation driven by two AAA batteries for more
than one year. Two ceramic chip antennas increase the link budget in a typical
indoor scenario with multipath fading effects.
Figure 1-1. AT86RF231 – Antenna Diversity Board
Application Note
