±30ppmA
Frequency Tolerance (at 25°C)
F ± 100 ppm (-40 to +85°C)
G ± 50 ppm (-40 to +85°C)
H ± 30 ppm (-40 to +85°C)
L ± 150 ppm (-40 to +125°C)
M ± 100 ppm (-40 to +125°C)
N ± 50 ppm (-40 to +125°C)
O ± 100 ppm (-40 to +105°C)
P ± 50 ppm (-40 to +105°C)
Q ± 30 ppm (-40 to +105°C)
Frequency Stability (over Temp.)
B 8.5pF
D 11pF
E 12pF
H 15pF
I 16pF
K 20pF
Q 10pF
V 8pF
Y 7pF
Load Capacitance
T
Tape & Reel
B
Bulk
Packaging MethodFrequency
Numerical Value,
maximum characters as
follows:
XX.XXXXXX
followed by “M” for MHz
For example:
AS
AT
AX
AA
AV
AB
AM
Product Family
Example Part Number: AM-20.000MAGE-T
Quartz Crystal Part Numbering System - Automotive Grade
AM 20.000M A G E T- -
