AFE7222
AFE7225
www.ti.com
SLOS711B –NOVEMBER 2011–REVISED MARCH 2012
Analog Front End Wideband Mixed-Signal Transceiver
Check for Samples: AFE7222, AFE7225
1 INTRODUCTION
1.1 FEATURES
1
– TX Path Interpolation by 2 or 4
• AFE7225
– RX Path Decimation by 2
– Dual 12-Bit 250MSPS TX DACs
– 3.0V/1.8V Supplies, Low Power
– Dual 12-Bit 125MSPS RX ADCs
– Fast Wakeup Modes for Half-Duplex
• AFE7222
– Coarse or Fine Digital Mixer
– Dual 12-Bit 130MSPS TX DACs
– Quadrature Modulation Corrections
– Dual 12-Bit 65MSPS RX ADCs
– Clock Input Divide/Multiply
• OPTIONS
– Serial LVDS or Interleaved Parallel CMOS
– Dual 12-Bit Auxiliary DACs
Interface
– Dual Input 12-Bit Auxiliary ADC
– 64-Pin QFN Package (9mm × 9mm)
1.2 APPLICATIONS
• Portable, Low Power Radio
• Wireless Infrastructure
• Point-to-Point Radio
• Pico-Cell BTS
1.3 DESCRIPTION
The AFE7225/7222 is an analog front end designed for full- or half-duplex radios. Over-sampling transmit
12-bit DACs provide output frequencies from baseband to Nyquist. Under-sampling receive 12-bit ADCs
allow analog inputs from baseband to ~230MHz. Most blocks within the AFE7225/7222 are independently
controlled for optimization of power consumption versus utilization. Two auxiliary control 12-bit DACs and
a dual input auxiliary monitoring 12-bit ADC are available via serial interface. Digital features include QMC
(quadrature modulation correction), interpolation, decimation, RMS/peak power meter and mixers with
independent NCOs for RX and TX path.
The AFE7225/7222 is available in a 64-pin 9x9mm QFN package (RGC). The AFE7225/7222 is built on
Texas Instrument’s low power analog CMOS process and is specified over the full industrial temperature
range (–40°C to 85°C).
