ADS8638EVM-PDK
ADCPro is a trademark of Texas Instruments.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
SPI is a trademark of Motorola, Inc.
All other trademarks are the property of their respective owners.
User's Guide
SBAU192A–July 2011–Revised February 2016
ADS8638EVM-PDK
ADS8638EVM-PDK
This user's guide describes the characteristics, operation, and use of the ADS8638EVM, both by itself and
as a part of the ADS8638EVM-PDK. This evaluation module (EVM) is designed to feature the ADS8638
but can also support the ADS8614 , ADS8618, or ADS8634 if installed. This family of devices includes
either an 8- or 12-bit, 1-MHz, multi-channel, successive approximation register (SAR) analog-to-digital
converters (ADCs). The EVM allows evaluation of all aspects of the ADS8638 device. A complete circuit
description as well as schematic diagram and bill of materials are included.
The following related documents are available for download through the Texas Instruments web site at
http://www.ti.com.
Table 1. EVM-Related Device Data Sheets
Device Literature Number
ADS8638 SBAS541A
OPA140 SBOS498A
OPA379 SBOS347D
REF5025 SBOS410E
SN74LVC1G17D SCES351R
