DEM-ADS7846
TOUCHSCREEN CONTROLLER
EVALUATION FIXTURE
FEATURES
● DEMONSTRATES ADS7846E
CAPABILITIES
● COMPATIBLE WITH ADS7843 AND
ADS7845
● INCLUDES 4-WIRE TOUCHSCREEN
● WINDOWS
®
95/98 COMPATIBLE
SOFTWARE
Windows is a registered trademark of Microsoft Corp.
DESCRIPTION
The DEM-ADS7846E is an evaluation tool for Burr-
Brown’s ADS7846E, a 4-wire touch-screen controller
which features direct battery measurement, tempera-
ture measurement, and touch-pressure measurement.
For a block diagram of the DEM-ADS7846E setup,
see Figure 1. The DEM-ADS7846E is designed to be
used with the DEM-CIB Computer Interface Board.
Included with the DEM-ADS7846E is Windows
95/98 compatible software which displays the touch
data, and exercises all other measurement capabilities
of the ADS7846E.
