User's Guide
SBAU134B–August 2008– Revised May 2011
ADS1174EVM, ADS1274EVM, ADS1174EVM-PDK, and
ADS1274EVM-PDK
Figure 1. ADS1274EVM (Left) and ADS1274EVM-PDK (Right)
This user's guide describes the characteristics, operation, and use of the ADS1174EVM and
ADS1274EVM, both by themselves and as part of the ADS1174EVM-PDK or ADS1274EVM-PDK. These
evaluation modules (EVMs) are evaluation boards for the ADS1274, a 24-bit multi-channel, delta-sigma
analog-to-digital converter (ADC), and the ADS1174, a 16-bit version of the ADS1274. The EVM allows
evaluation of all aspects of the ADS1174 or ADS1274 devices. Complete circuit descriptions, schematic
diagrams, and bills of material are included in this document.
The following related documents are available through the Texas Instruments web site at www.ti.com.
EVM-Compatible Device Data Sheets
Device Literature Number Device Literature Number
ADS1274 SBAS367B OPA1632 SBOS286A
ADS1174 SBAS373A SN74LVC2G157 SCES207K
REF5025 SBOS410 TPS73018 SBVS054H
REF3125 SBVS046C TPS65131 SLVS493B
OPA2350 SBOS099C PCA9535 SCPS129H
ADCPro is a trademark of Texas Instruments.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
SPI is a trademark of Motorola.
I
2
C is a trademark of NXP Semiconductors.
NI-VISA is a trademark of National Instruments.
All other trademarks are the property of their respective owners.
