EVAL-ADM1260EBZ User Guide
UG-932
One Technology Way • P.O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluating the
ADM1260 Super Sequencer with Interchip Bus and
Nonvolatile Fault Recording
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Rev. 0 | Page 1 of 20
FEATURES
Full functional support evaluation kit for the ADM1260
I²C interface supports all device related software
Interchip bus simplifies multidevice cascading and
sequencing operation
10 adjustable voltages reference for input emulation
Switch controlled, open-drain/push-pull digital inputs
Extra headers for easy probing
Includes point to point patch cables for easy wiring
EVAL-ADM1260EBZ EVALUATION KIT CONTENTS
EVAL-ADM1260CSZ evaluation board and sample silicons
ADM1260 device socket
8-way, 100 mm micro match ribbon cable
Patch cables
ADDITIONAL HARDWARE NEEDED
USB to I²C dongle USB-SDP-CABLEZ
9 V to 14.4 V power supply
SOFTWARE NEEDED
ADI Power Studio
GENERAL DESCRIPTION
The EVA L-ADM1260CSZ is a compact, full-feature evaluation
board for the ADM1260 that comes in the EVAL -ADM1260EBZ
evaluation kit.
Ten programmable driver outputs, Pins PDO1 to PDO10 (PDOx),
and five dual-function inputs, Pins VX1 to VX5 (VXx), along
with five selectable input attenuators that allow supervision of
supplies, Pins VP1 to VP4 (VPx), and Pin VH give users flexibility
and allows a wide range of application setups.
Ten LEDs give users direct visual indication on variations in the
input board status. There is one LED to indicate the board power
supply status.
The switches on the board allow the user to change the device
address easily.
The evaluation kit supports I
2
C communication, allowing users
to communicate with the ADM1260 devices. The evaluation kit
also supports cascade setup so multiple evaluation boards can
connect and share the same I
2
C bus.
The EVAL-ADM1260CSZ is fully compatible with the ADI Power
Studio™ software, to download this software, go to the ADM1260
product page.
Users need a USB-SDP-CABLEZ dongle to use the evaluation
software tools. Only one dongle is required in a multiboard
cascade setup. One device socket is included in each kit. The
ADM1260 data sheet provides additional information and must
be consulted when using the evaluation board.
