EVAL-AD5339DBZ User Guide
UG-980
One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluating the AD5339 12-Bit, Dual-Channel, Voltage Output Digital-to-Analog
Converter (DAC)
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Rev. 0 | Page 1 of 13
FEATURES
Full featured evaluation board (EVAL-AD5339DBZ)
in conjunction with nanoDAC motherboard
(EVAL-MBnanoDAC-SDZ)
On-board references
Various link options
PC control in conjunction with Analog Devices, Inc., system
demonstration platform (SDP)
EVALUATION KIT CONTENTS
EVAL-AD5339DBZ daughter board
EVAL-MBnanoDAC-SDZ motherboard
USB cable
SOFTWARE REQUIRED
EVAL-AD5339DBZ evaluation software
HARDWARE REQUIRED
EVAL-SDP-CB1Z controller board (SDP-B controller board),
must be purchased separately
GENERAL DESCRIPTION
This user guide details the operation of the EVA L-AD5339DBZ
evaluation board for the AD5339, a 12-bit, dual-channel, voltage
output DAC. The AD5339 operates from a single 2.5 V to 5.5 V
supply.
The EVA L -AD5339DBZ is designed to quickly prototype AD5339
circuits and reduce design time. The EVA L -AD5339DBZ
evaluation board interfaces with the USB port of a PC via the
SDP-B controller board. Software can be downloaded via the
EVA L-AD5339DBZ product page, allowing users to program the
AD5339.
This evaluation board requires the SDP-B controller board,
which is available to order on the Analog Devices website.
Full specifications for the AD5339 are listed in the AD5339 data
sheet available from Analog Devices, Inc., and should be
consulted in conjunction with this user guide when using the
evaluation board.
PHOTOGRAPH OF THE EVAL-AD5339DBZ, EVAL-MBnanoDAC-SDZ, AND EVAL-SDP-CB1Z
14515-001
Figure 1.
