16-Bit 1 MSPS PulSAR
Unipolar ADC with Reference
Data Sheet
AD7653
Rev. B Document Feedback
Information furnished by Analog Devices is believed to be accurate and reliable. However, no
responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other
rights of third parties that may result from its use. Specifications subject to change without notice. No
license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
Trademarks and registered trademarks are the property of their respective owners.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781.329.4700 ©2003–2016 Analog Devices, Inc. All rights reserved.
Technical Support www.analog.com
FEATURES
Throughput:
1 MSPS (Warp mode)
800 kSPS (Normal mode)
666 kSPS (Impulse mode)
16-bit resolution
Analog input voltage range: 0 V to 2.5 V
No pipeline delay
Parallel and serial 5 V/3 V interface
SPI
®/QSPI
TM
/MICROWIRE
TM
/DSP compatible
Single 5 V supply operation
Power dissipation
92 mW typ @ 666 kSPS, 138 µW @ 1 kSPS without REF
128 mW typ @ 1 MSPS with REF
48-lead LQFP and 48-lead LFCSP packages
Pin-to-pin compatible with PulSAR ADCs
APPLICATIONS
Data acquisition
Instrumentation
Digital signal processing
Spectrum analysis
Medical instruments
Battery-powered systems
Process control
GENERAL DESCRIPTION
The AD7653 is a 16-bit, 1 MSPS, charge redistribution SAR
analog-to-digital converter that operates from a single 5 V
power supply. The part contains a high speed 16-bit sampling
ADC, internal conversion clock, internal reference, error
correction circuits, and both serial and parallel system interface
ports. It features a very high sampling rate mode (Warp), a fast
mode (Normal) for asynchronous conversion rate applications,
and a reduced power mode (Impulse) for low power applica-
tions where power is scaled with the throughput. The AD7653
is fabricated using Analog Devices’ high performance, 0.6
micron CMOS process, with correspondingly low cost. It is
available in a 48-lead LQFP and a tiny 48-lead LFCSP with
operation specified from –40°C to +85°C.
FUNCTIONAL BLOCK DIAGRAM
02966-0-001
SWITCHED
CAP DAC
16
CONTROL LOGIC AND
CALIBRATION CIRCUITRY
CLOCK
AD7653
DATA[15:0]
BUSY
RD
CS
SER/PAR
OB/2C
OGND
OVDD
DGNDDVDD
AVDD
AGND
REF REFGND
IN
INGND
PD
RESET
SERIAL
PORT
PARALLEL
INTERFACE
CNVSTWARP IMPULSE
REF
REFBUFIN
PDBUF
PDREF
BYTESWAP
Figure 1.
Table 1. PulSAR™ Selection
Type/kSPS 100–250 500–570
800–
1000
Pseudo-
Differential
AD7651
AD7660/AD7661
AD7650/AD7652
AD7664/AD7666
AD7653
AD7667
True Bipolar AD7663 AD7666 AD7671
True
Differential
AD7675
AD7676
AD7677
18-Bit AD7678 AD7679 AD7674
Multichannel/
Simultaneous
AD7654
AD7655
PRODUCT HIGHTLIGHTS
1. Fast Throughput.
The AD7653 is a 1 MSPS, charge redistribution, 16-bit SAR
ADC with internal error correction circuitry.
2. Internal Reference.
The AD7653 has an internal reference with a typical
temperature drift of 7 ppm/°C.
3. Single-Supply Operation.
The AD7653 operates from a single 5 V supply. In Impulse
mode, its power dissipation decreases with the throughput.
4. Serial or Parallel Interface.
Versatile parallel or 2-wire serial interface arrangement is
compatible with both 3 V and 5 V logic.
