Accuracy and exibility. Stability and speed. Honeywell
Sensing and Control (S&C) offers an impressive array of
temperature sensors, each designed to provide enhanced
reliability, repeatability, precision, and responsiveness. These
temperature sensors are designed to maximize your component
and product performance for most any potential application.
FEATURES
PACKAGED TEMPERATURE
PROBES
LTP Series.
Features: Response time [T63.2% of 25
°C to 85 °C step]: stirred silicon oil <15 s;
stirred water <15 s; air flow 10 m/s <20 s
• Accuracy: -40 °C to 25 °C [-40 °F to 77
°F]: ±2.5 °C, 25 °C to 100 °C [77 °F to 212
°F]: ±0.8 °C, 100 °C to 125 °C [212 °F to
257 °F]: ±2.0 °C, 125 °C to 150 °C [257 °F
to 302 °F]: ±3.5 °C • Electrical interfaces
are Deutsch 2 position (AMP Minitimer,
Bosch Kompakt, Delphi Metri-Pack, AMP
seal 16, and AMP Superseal connector
style variants available upon request)
• Probe length options: 20 mm to 50 mm
• Retainer ring with hex provides complete
location for socket wrench in axial and
radial directions, enabling the operator to
first locate the sensor inside the socket
freely and more easily install the sensor
• Ingress protection: IP67 • Vibration of 30
g sine wave,10 Hz to 2000 Hz
• Mechanical shock of 50 g • Service
pressure: 10 bar • Burst pressure: 40
bar • Wire harness (with or without a
connector) or other sensing elements
(PTC or RTD) available upon request
Temperature Sensors
Line Guide
continued on page 9
Benets: Durable, closed-tip design
maximizes reliability in harsh applications.
Sensor’s thermistor sensing element
effectively senses gases, liquids or solids
because of its enhanced sensitivity,
accuracy and reliability. Easy-to-install
threaded mounting provides reliable
operation in harsh environments.
Numerous options—from mechanical
and electrical interface—simplify
installation, allow customers to meet
specific application needs, and facilitate
backwards compatibility with most existing
applications. Zero NRE (non-recurring
engineering) costs for configurations.
Reduces cost of ownership due to BOM
(bill of materials), engineering, testing,
NRE and tooling. Reduces design costs
due to plug-and-play options, backwards
integration, flexible offering, customization
and non-standard offering. Potential
transportation applications include
temperature sensing for ambient air,
automatic transmission systems, engine
air inlet systems, engine cooling systems,
engine lubrication systems, fuel systems,
Haldex coupling systems, and hydraulic
pump systems.
R300 Series.
Features: Wide temperature-range
• Stainless steel construction • Enhanced
response time • Enhanced accuracy
• Enhanced reliability • Linear output
• Extended life
Benets: Robust, stainless steel closed-
tip design for reliability in most aggressive
environments, while still providing
enhanced response time. One-piece
sensor with integral connector for potential
use in heavy duty vehicle engine exhaust
gas recirculation systems, fluid or air
temperature sensing within the engine
environment or HVAC, or refrigeration
compressor equipment.
500 Series.
Features: Choice of custom or existing
designs • Wide selection of housing,
resistance, and termination options • Wide
operating temperature range
Benets: Housing material ranges from
all plastic to all-metal, and accommodates
air/gas, fluid immersion or surface sensing
requirements. Full range of custom or
off-the-shelf thermistor and RTD-based
solutions for a wide variety of potential
industrial, transportation, and aerospace
applications.
That’s why more customers worldwide call the industry’s most
trusted name for:
• Enhanced accuracy and stability
• Strong standard technology platforms
• A wide variety of housings and termination styles
• Easy-to-customize platforms
• High-temp product line expansion sensing capability
• Comprehensive technical support
