ZXTN2038F
SOT23 80 volt NPN silicon planar medium power
transistor
Summary
V
(BR)CEV
> 80V
V
(BR)CEO
> 60V
I
c(cont)
= 1A
V
ce(sat)
< 500mV @ 1A
Complementary type
ZXTP2039F
Description
This transistor combines high gain, high current operation and low saturation voltage making it
ideal for power MOSFET gate driving and low loss power switching.
Features
• Low saturation voltage for reduced power dissipation
• 1 to 2 amp high current capability
• Pb-free
• SOT23 package
Applications
• Power MOSFET gate driving
• Low loss power switching
Ordering information
Device marking
N38
Device Reel size Tape width Quantity per reel
ZXTN2038FTA 7” 8mm 3,000
ZXTN2038FTC 13” 8mm 10,000
