Product features
• Six winding, surface mount devices that
offer more than 500 usable inductor or
transformer configurations
• High power density and low profile
• Low radiated noise and tightly coupled
windings
• Power range from 1 Watt – 70 Watts
• Frequency range to over 1 MHz
• 500 Vac Isolation
• Ferrite core material
VP
VERSA-PAC® Inductors and Transformers (Surface Mount)
Technical Data 4301
Effective August 2017
Supersedes March 2007
Applications
• Inductors: buck, boost, coupled, choke,
filter, resonant, noise filtering, differential,
forward, common mode
• Transformers: flyback, feed forward, push-
pull, multiple output, inverter, step-up, step-
down, gate drive, base drive, wide band,
pulse, control, impedance, isolation,
bridging, ringer, converter, autoAutomotive
electronics (under hood, interior/exterior)
• Telematics
• GPS
• LED Lighting
• LCD Display
• Portable media devices
Environmental data
• Storage temperature range (component):
-55 °C to +125 °C
• Operating temperature range:
-40
°C to +125 °C
(ambient plus self-temperature rise)
• Solder reflow temperature:
J-STD-020 (latest revision) compliant
