下载
GATE
SRC
VCC
SEN
GND
AC1
PGND
AC2
VP
ADJ
TPS92560
L
1
C
VCC
Q
1
C
OUT
D
3
R
ADJ1
R
ADJ2
C
ADJ
R
SEN
C
IN
R
1
D
1
D
2
Power
Source
LED
C
VP
Product
Folder
Sample &
Buy
Technical
Documents
Tools &
Software
Support &
Community
Reference
Design
TPS92560
SNVS900B –DECEMBER 2012–REVISED DECEMBER 2015
TPS92560 Simple Led Driver for MR16 and AR111 Applications
1 Features 3 Description
The TPS92560 is a simple LED driver designed to
1
• Controlled peak input current to prevent over-
drive high-power LEDs by drawing constant current
stressing of the electronic transformer
from the power source. The device is ideal for MR16
• Allows Either Step-Up or Step-Up/Down Operation
and AR111 applications, which require good
• Compatible to Generic Electronic Transformers
compatibility to DC and AC voltages and electronic
transformers. The hysteretic control scheme does not
• Compatible to Magnetic Transformers and DC
need control loop compensation while providing the
Power Supplies
benefits of fast transient response and high power
• Integrated Active Low-Side Input Rectifiers
factor. The patent pending feedback control method
• Compact and Simple Circuit
allows the output power to be determined by the
number of LED used without component change. The
• >85% Dfficiency (12-VDC Input)
TPS92560 supports both boost and SEPIC
• Power Factor > 0.9 (Full Load With AC input)
configurations for the use of different LED modules.
• Hysteretic Control Scheme
Device Information
(1)
• Output Overvoltage Protection
PART NUMBER PACKAGE BODY SIZE (NOM)
• Overtemperature Shutdown
TPS92560 HVSSOP (10) 3.00 mm × 3.00 mm
• 10-pin Thermally Enhanced Very-Thin Fine Pitch
Small-Outline Package
(1) For all available packages, see the orderable addendum at
the end of the data sheet.
2 Applications
• MR16/AR111 LED Lamps
• Lighting System Using Electronic Transformer
• General Lighting Systems That Require a Boost /
SEPIC LED Driver
Typical Application Schematic
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
