Freescale Semiconductor
Design Checklist
© 2014 Freescale Semiconductor, Inc. All rights reserved.
About this document
This document provides recommendations for new designs based on the P2041. It may also be useful
in debugging newly-designed systems by highlighting those aspects of a design that merit special
attention during initial system start-up.
Each section has a pin termination checklist or a system-level checklist, or sometimes both.
Before you begin
Ensure you are familiar with the following Freescale documents before proceeding:
• P2041 QorIQ Integrated Processor Hardware Specifications (P2041EC)
• P2041 QorIQ Integrated Processor Reference Manual (P2041RM)
• P2041 Chip Errata (P2041CE)
• QorIQ Data Path Acceleration Architecture (DPAA) Reference Manual (DPAARM)
Document Number: AN4402
Rev. 0, 04/2014
Contents
1. Simplifying the first phase of design . . . . . . . . . . . . . 2
2. Power design recommendations . . . . . . . . . . . . . . . . . 6
3. Power-on reset recommendations . . . . . . . . . . . . . . . 11
4. DDR recommendations . . . . . . . . . . . . . . . . . . . . . . 13
5. SerDes recommendations . . . . . . . . . . . . . . . . . . . . . 15
6. eLBC recommendations . . . . . . . . . . . . . . . . . . . . . . 16
7. DMA recommendations . . . . . . . . . . . . . . . . . . . . . . 18
8. PIC recommendations . . . . . . . . . . . . . . . . . . . . . . . . 19
9. IEEE 1588 recommendations . . . . . . . . . . . . . . . . . . 20
10. Ethernet management recommendations . . . . . . . . . 21
11. TSEC recommendations . . . . . . . . . . . . . . . . . . . . . . 22
12. UART recommendations . . . . . . . . . . . . . . . . . . . . . 24
13. I2C recommendations . . . . . . . . . . . . . . . . . . . . . . . . 25
14. eSDHC recommendations . . . . . . . . . . . . . . . . . . . . 26
15. eSPI recommendations . . . . . . . . . . . . . . . . . . . . . . . 27
16. USB recommendations . . . . . . . . . . . . . . . . . . . . . . . 28
17. GPIO recommendations . . . . . . . . . . . . . . . . . . . . . . 30
18. DFT recommendations . . . . . . . . . . . . . . . . . . . . . . . 32
19. Power management recommendations . . . . . . . . . . . 32
20. Trust recommendations . . . . . . . . . . . . . . . . . . . . . . . 33
21. Clock recommendations . . . . . . . . . . . . . . . . . . . . . . 34
22. System control recommendations . . . . . . . . . . . . . . . 34
23. Debug recommendations . . . . . . . . . . . . . . . . . . . . . 35
24. JTAG recommendations . . . . . . . . . . . . . . . . . . . . . . 37
25. No connect recommendations . . . . . . . . . . . . . . . . . . 42
26. Thermal recommendations . . . . . . . . . . . . . . . . . . . . 42
27. Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
P2041/P2040 QorIQ Integrated
Processor Design Checklist
