TPD4F202, TPD6F202
www.ti.com
SLLS800 –JUNE 2010
FOUR-, SIX-CHANNEL EMI FILTER WITH ESD PROTECTION FOR LCD DISPLAY
Check for Samples: TPD4F202, TPD6F202
1
FEATURES
• Four-, Six-Channel EMI Filtering and ESD (R = 100 Ω, C
TOTAL
= 30 pF)
Protection for Data Lines
• Low 10-nA Leakage Current
• Excellent filter Performance
• Space-Saving WCSP Package and
– >40dB Attenuation at 1GHz-3GHz Flow-Through Pin Mapping Provides Optimum
Performance in Portable Applications
– -3dB Bandwidth at 108MHz
– 70 dB Crosstalk Attenuation at 100 MHz
APPLICATIONS
• Exceeds IEC61000-4-2 (Level 4) ESD
• LCD Display Interface
Protection Requirements
• Memory Interface
– ±25-kV IEC 61000-4-2 Contact Discharge
• SVGA Video Connections
– ±25-kV IEC 61000-4-2 Air-Gap Discharge
• Keypad
– ±15-kV Human-Body Model (HBM)
• Data Lines in Portables
• Pi-Style C-R-C Filter Configuration Offers
Symmetric Filter Performance
TPD4F202 TPD6F202
YFU PACKAGE YFU PACKAGE
ORDERING INFORMATION
ORDERABLE
T
A
PACKAGE
(1) (2)
PACKAGE DIMENSION TOP-SIDE MARKING
PART NUMBER
Length = 2.36 mm, Width = 1.053 mm,
TPD6F202YFUR YMS5WS
Pitch = 0.4 mm, Height = 0.32 mm)
–40°C to 85°C WCSP – YFU
Length = 1.56 mm, Width = 1.053 mm,
TPD4F202YFUR YMS57S
Pitch = 0.4 mm, Height = 0.32 mm)
(1) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
web site at www.ti.com.
(2) Package drawings, thermal data, and symbolization are available at www.ti.com/packaging.
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date.
Copyright © 2010, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
