Application Report
SPRAAK5B–March 2012
Using the TMS320C642x Bootloader
Daniel Allred....................................................................................................................................
ABSTRACT
This document describes the functionality of the C642x ROM bootloader software. Please note that the
ROM bootloader requires use of Application Image Script (AIS) as the primary data format for loading
code/data. AIS is a Texas Instruments, Inc. proprietary data format that is explained in detail in Section 3
of this document.
Project collateral and source code discussed in this application report can be downloaded from the
following URL: http://www-s.ti.com/sc/techlit/spraak5.zip .
