THERMOTAB
TO-220AB
TO-202AB
TO - 92
Selected Packages*
U.L. RECOGNIZED
File #E71639
AK
G
Teccor Electronics, Inc. 5-1 Sensitive SCRs
(972) 580-7777
Sensitive SCRs
(0.8 – 10 Amps)
5
General Description
The Teccor Electronics, Inc. line of sensitive SCR semiconduc-
tors are half-wave unidirectional gate-controlled rectifiers (SCR-
thyristor) which complement Teccor's line of power SCRs. This
group of packages offers ratings of 0.8-10 amps, and 50-600
volts with gate sensitivities of 12-500 microamps. If gate currents
in the 10-50 milliamp ranges are required, please consult Tec-
cor's non-sensitive SCR technical data sheets.
Electrically Isolated Packages
This group of Teccor sensitive SCRs is available in a choice of
three different product packages. The TO-220AB and TO-92 are
electrically isolated where the case or tab is internally isolated to
allow the use of low cost assembly and convenient packaging
techniques.
Glass Passivation
Teccor's line of SCRs features glass-passivated junctions to
ensure long term device reliability and parameter stability. Tec-
cor's glass offers a rugged, reliable barrier against junction con-
tamination.
Tape-and-reel packaging is available for the TO-92 package.
Please consult factory for more information.
Variations of devices covered in this data sheet are available for
custom design applications. Please consult the factory for more
information.
Features
• Electrically-isolated To-220AB package
• High Voltage Capability up to 600 Volts
• High Surge Capability — up to 100 Amps
• Glass Chip Passivation
