Table 1: Main Product Characteristics
I
F(AV)
3 A
V
RRM
600 V
I
R
(max)
100 µA
T
j
175°C
V
F
(typ)
1.0 V
t
rr
(typ)
35 ns
STTH3R06
TURBO 2 ULTRAFAST HIGH VOLTAGE RECTIFIER
SMB
STTH3R06U
SMC
STTH3R06S
DO-201AD
STTH3R06
KA
September 2004 REV. 2
FEATURES AND BENEFITS
■ Ultrafast switching
■ Low forward voltage drop
■ Low thermal resistance
■ Low leakage current (platinium doping)
DESCRIPTION
The STTH3R06, which is using ST Turbo 2 600V
technology, is specially suited for use in switching
power supplies, inverters and as a free wheeling
diode.
Table 2: Order Codes
Part Number Marking
STTH3R06 STTH3R06
STTH3R06RL STTH3R06
STTH3R06U R06U
STTH3R06S R6S
