70908HKIM No. A1131-1/9
STK681-200-E
Overview
The STK681-200-E is a hybrid IC for use in current control forward/reverse DC motor driver with brush.
Applications
• Office photocopiers, printers, etc.
Features
• Allows forward, reverse, and brake operations in accordance with the external input signal.
• 4.2A startup output current and 8A peak brake output current.
• Incorporating a current detection resistor (0.10Ω), fixed current control is possible.
Specifications
Absolute maximum ratings at Tc = 25°C
Parameter Symbol Conditions Ratings unit
Maximum supply voltage 1
V
CC
1 max V
CC
2=0V 52 V
Maximum supply voltage 2
V
CC
2 max No signal -0.3 to +7.0 V
Input voltage
V
IN
max Logic input pins -0.3 to +7.0 V
Output current
I
O
max V
CC
2=5.0V, DC current 4.2 A
Brake current I
O
B max V
CC
2=5.0V, square wave current, operating time 60ms
(single pulse)
8A
Operating substrate temperature
Tc max 105 °C
Junction temperature
Tj max 150 °C
Storage temperature
Tstg -40 to +125 °C
Ordering number : EN*A1131
Thick-Film Hybrid IC
Forward/Reverse Motor Driver
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
'
s products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'
sproductsor
equipment.
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
