Products > LEDs > Thru-Hole > Round > 5mm > Standard > Standard Intensity

Features / Options Applications / Uses

State-of-the-Art, High Brightness Chip

Technology

Choice of Colors and Lens Finishes

Lead Frame / Lens Casting Reliability

Easy-to-Solder Leads, Tin Finish

Available Bulk or on Tape and Reel

Lead Trimming and Forming Available

Custom Shapes, Easily Tooled, Low

Minimum

Board or Panel Indication or

Illumination

Annunciator and Control Panels

Telecom Switches and Central Station

Equipment

Large Panel Indicators

Part Number: Brightness

Dice

Material

Emitted

Color

Peak

Wavelength

Epoxy

Lens

Operating

Typ Vf

(V)

Intensity

Typ,

mcd @

20 mA

View

Angle

Theta

SSL-LX5093AD STANDARD GaAsP Amber 605 Diffused 2.1 30 60

SSL-LX5093AT STANDARD GaAsP Amber 605

Color

Tinted

2.1 80 30

SSL-LX5093GD STANDARD GaP Green 565 Diffused 2.0 30 60

SSL-LX5093HD STANDARD GaP Red 700 Diffused 2.1 30 60

SSL-LX5093ID STANDARD GaAsP Red 635 Diffused 2.0 40 60

SSL-LX5093IGW STANDARD GaAsP Red/Green 635

White

Diffused

2.1 30 60

SSL-LX5093IT STANDARD GaAsP Red 635

Color

Tinted

28030

SSL-LX5093SBC/A STANDARD SiC Blue 430 Clear 3.5 100 30

SSL-LX5093SBD STANDARD SiC Blue 430 Diffused 4.5 25 20

SSL-LX5093SGC/B STANDARD GaP Green 565 Clear 2.1 300 30
