Products > LEDs > Thru-Hole > Round > 5mm > Standard > High Intensity

Features / Options Applications / Uses

State-of-the-Art, High Brightness Chip

Technology

Choice of Colors and Lens Finishes

Lead Frame / Lens Casting Reliability

Easy-to-Solder Leads, Tin Finish

Available Bulk or on Tape and Reel

Lead Trimming and Forming Available

Custom Shapes, Easily Tooled, Low

Minimum

Board or Panel Indication or

Illumination

Annunciator and Control Panels

Telecom Switches and Central Station

Equipment

Large Panel Indicators

Part Number: Brightness

Dice

Material

Emitted

Color

Peak

Wavelength

Epoxy

Lens

Operating

Typ Vf

(V)

Intensity

Typ,

mcd @

20 mA

View

Angle

Theta

SSL-LX5093PC HIGH InGaN Pink - Clear 3.5 2200 20

SSL-LX5093PGD STANDARD GaP Green 555 Diffused 2.1 30 60

SSL-LX5093PGT STANDARD GaP Green 555

Color

Tinted

2.0 50 30

SSL-LX5093SIC HIGH AlInGaP Red 636 Clear 2.0 1800 30

SSL-LX5093SID HIGH AlInGaP Red 636 Diffused 2.0 700 60

SSL-LX5093SOC HIGH AlInGaP Orange 610 Clear 2.0 2500 30

SSL-LX5093SOD HIGH AlInGaP Orange 610 Diffused 2.0 850 60

SSL-LX5093SRC/DU STANDARD GaAlAs Red 660 Clear 1.7 1300 30

SSL-LX5093SRC/DV STANDARD GaAlAs Red 660 Clear 1.7 1600 30

SSL-LX5093SRC/DW STANDARD GaAlAs Red 660 Clear 1.7 2000 30
