This is information on a product in full production.
July 2012 Doc ID 14723 Rev 8 1/115
1
SPC560P44L3, SPC560P44L5
SPC560P50L3, SPC560P50L5
32-bit Power Architecture
®
based MCU with 576 KB Flash memory
and 40 KB SRAM for automotive chassis and safety applications
Datasheet production data
Features
■ 64 MHz, single issue, 32-bit CPU core complex
(e200z0h)
– Compliant with Power Architecture
®
embedded category
– Variable Length Encoding (VLE)
■ Memory organization
– Up to 512 KB on-chip code flash memory
with ECC and erase/program controller
– Additional 64 (4 × 16) KB on-chip data flash
memory with ECC for EEPROM emulation
– Up to 40 KB on-chip SRAM with ECC
■ Fail safe protection
– Programmable watchdog timer
– Non-maskable interrupt
– Fault collection unit
■ Nexus L2+ interface
■ Interrupts
– 16-channel eDMA controller
– 16 priority level controller
■ General purpose I/Os individually
programmable as input, output or special
function
■ 2 general purpose eTimer units
– 6 timers each with up/down count
capabilities
– 16-bit resolution, cascadable counters
– Quadrature decode with rotation direction
flag
– Double buffer input capture and output
compare
■ Communications interfaces
– 2 LINFlex channels (LIN 2.1)
– 4 DSPI channels with automatic chip select
generation
– 1 FlexCAN interface (2.0B Active) with 32
message objects
– 1 safety port based on FlexCAN with 32
message objects and up to 7.5 Mbit/s
capability; usable as second CAN when not
used as safety port
– 1 FlexRay™ module (V2.1) with selectable
dual or single channel support, 32
message objects and up to 10 Mbit/s
(512 KB device only)
■ Two 10-bit analog-to-digital converters (ADC)
– 2 × 11 input channels, + 4 shared channels
– Conversion time < 1 µs including sampling
time at full precision
– Programmable ADC Cross Triggering Unit
(CTU)
– 4 analog watchdogs with interrupt
capability
■ On-chip CAN/UART bootstrap loader with Boot
Assist Module (BAM)
■ 1 FlexPWM unit: 8 complementary or
independent outputs with ADC synchronization
signals
Table 1. Device summary
Package
Part number
448 KB Flash 576 KB Flash
LQFP144 SPC560P44L5 SPC560P50L5
LQFP100 SPC560P44L3 SPC560P50L3
LQFP100 (14 x 14 x 1.4 mm)
LQFP144 (20 x 20 x 1.4 mm)
www.st.com
