Freescale Semiconductor
Product Brief
Document Number: MPC5510PB
Rev. 2, 5/2008
Contents
© Freescale Semiconductor, Inc., 2007, 2008. All rights reserved.
The MPC5510 is a new family of next generation
microcontrollers built on the Power Architecture.
This document describes the features of the family and
the options available on the devices in this family. It also
provides some important electrical and physical
characteristics of these devices.
The MPC5510 family of 32-bit microcontrollers is
Freescale Semiconductor’s latest achievement in
integrated automotive application controllers. It belongs
to an expanding family of automotive-focused products
designed to address the next wave of central body and
gateway applications within the vehicle. Freescale’s
advanced and cost efficient host processor core of the
MPC5510 automotive controller family is compatible
with the Power Architecture Book E architecture. It
operates at speeds up to 80 MHz and offers high
performance processing optimized for low-power
consumption. It capitalizes on the available development
infrastructure of the current Power Architecture devices
and will be supported with software drivers, operating
1 Application Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 Body Controller Application Example . . . . . . . . . . . 2
1.2 Gateway Application Example. . . . . . . . . . . . . . . . . 3
2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 MPC5510 Family Comparison. . . . . . . . . . . . . . . . . 3
2.2 Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Critical Performance Parameters . . . . . . . . . . . . . . 7
2.4 Packages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 Chip-Level Features . . . . . . . . . . . . . . . . . . . . . . . . 9
2.6 Module Features . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Developer Environment. . . . . . . . . . . . . . . . . . . . . . . . . . 21
MPC5510 Family Product Brief
32-Bit Power Architecture™ Microcontrollers for Body
Electronics
