Intellimod™ L1-Series
Three Phase
IGBT Inverter + Brake
150 Amperes/1200 Volts
PM150RL1A120
1
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
www.pwrx.com
11/12 Rev. 2
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
£ Complete Output Power
Circuit
£ Gate Drive Circuit
£ Protection Logic
– Short Circuit
– Over Temperature
Using On-chip
Temperature Sensing
– Under Voltage
£ Low Loss Using Full Gate
CSTBT
™
IGBT Chip
Applications:
£ Inverters
£ UPS
£ Motion/Servo Control
£ Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM150RL1A120 is a 1200V,
150 Ampere Intellimod™ Intelligent
Power Module.
Type Current Rating V
CES
Amperes Volts (x 10)
PM 150 120
Outline Drawing and Circuit Diagram
Dimensions Inches Millimeters
A 5.31 135.0
B 4.33±0.02 110±0.5
C 4.33 110.0
D 3.07 78.0±0.5
E 2.81 71.5
F 2.62 66.5
G 1.37 34.7
H 1.32 33.6
J 0.95+0.04/-0.01 24.1+1.0/-0.5
K 1.02 26.0
L 1.59 40.5
M 0.79 20.0
N 0.65 16.5
P 0.43±0.01 11.0±0.3
Q 1.19 30.15
R 0.43 11.0
Dimensions Inches Millimeters
S 0.51 13.0
T 0.16 4.0
U 0.1 Dia. Dia.2.5
V 0.02 Sq. Sq. 0.5
W M5 Metric M5
X 0.22 Dia. Dia. 5.5
Y 0.24 Rad. Rad. 6
Z 0.39 10.0
AA 0.13 3.25
AB 0.08 2.0
AC 0.24 6.05
AD 0.71 18.0
AE 0.46 11.7
AF 0.74 18.7
AG 0.41 10.5
AH 0.85 21.5
B
K
K
L
D
M
M
N
A
S
T
F
E
Q
Z
AA
Z
Z
P
J
R
G
H
C
V SQ. PIN
(19 TYP.)
X (4
PLACES)
AC
AC
AE
AG
AG
W (6
PLACES)
Y
(4 PLACES)
W V
14589121319
U
B
N
P
AB
19 FO
17 VN
14 VN1
11 WP
8 VVP1
2 UFO
6 VFO
5 VVPC
3 UP
7 VP
9 VWPC
10 WFO
12 VWP1
1 VUPC
4 VUP1
16 UN
15 Br
18 W
N
13 VNC
TERMINAL
CODE
U
(2 TYP.)
AF
AC
AH
AD
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
PU
Br
VWNB
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
U
N
F
O
V
NC
W
N
V
N1
V
N
V
WPC
W
P
W
FO
V
WP1
V
VPC
V
P
V
FO
V
VP1
V
UPC
U
P
U
FO
V
UP1
