© Semiconductor Components Industries, LLC, 2015
May, 2015 − Rev. 2
1 Publication Order Number:
NSS40302P/D
NSS40302PDR2G
Complementary 40 V, 6.0 A,
Low V
CE(sat)
Transistor
ON Semiconductor’s e
2
PowerEdge family of low V
CE(sat)
transistors are surface mount devices featuring ultra low saturation
voltage (V
CE(sat)
) and high current gain capability. These are designed
for use in low voltage, high speed switching applications where
affordable efficient energy control is important.
Typical applications are low voltage motor controls in mass storage
products such as disc drives and tape drives. In the automotive
industry they can be used in air bag deployment and in the instrument
cluster. The high current gain allows e
2
PowerEdge devices to be
driven directly from PMU’s control outputs, and the Linear Gain
(Beta) makes them ideal components in analog amplifiers.
Features
• NSV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q101
Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
MAXIMUM RATINGS (T
A
= 25°C)
Rating Symbol Max Unit
Collector-Emitter Voltage NPN
PNP
V
CEO
40
−40
Vdc
Collector-Base Voltage NPN
PNP
V
CBO
40
−40
Vdc
Emitter-Base Voltage NPN
PNP
V
EBO
6.0
−7.0
Vdc
Collector Current − Continuous NPN
PNP
I
C
3.0
−3.0
A
Collector Current − Peak NPN
PNP
I
CM
6.0
−6.0
A
Electrostatic Discharge ESD HBM Class 3B
MM Class C
Stresses exceeding those listed in the Maximum Ratings table may damage the
device. If any of these limits are exceeded, device functionality should not be
assumed, damage may occur and reliability may be affected.
Device Package Shipping
†
ORDERING INFORMATION
NSS40302PDR2G SOIC−8
(Pb−Free)
2500 /
Tape & Reel
DEVICE MARKING
SOIC−8
CASE 751
STYLE 16
www.onsemi.com
40 VOLTS, 6.0 AMPS
COMPLEMENTARY LOW
V
CE(sat)
TRANSISTOR
EQUIVALENT R
DS(on)
80 mW
COLLECTOR
7,8
2
BASE
1
EMITTER
COLLECTOR
5,6
4
BASE
3
EMITTER
1
8
C40302
AYWWG
G
1
8
C40302 = Specific Device Code
A = Assembly Location
Y = Year
WW = Work Week
G = Pb−Free Package
(Note: Microdot may be in either location)
NSV40302PDR2G SOIC−8
(Pb−Free)
2500 /
Tape & Reel
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
