Semiconductor Components Industries, LLC, 2001
September, 2001 – Rev. 3
1 Publication Order Number:
NL27WZ02/D
NL27WZ02
Dual 2-Input NOR Gate
The NL27WZ02 is a high performance dual 2–input NOR Gate
operating from a 2.3 V to 5.5 V supply.
• Extremely High Speed: t
PD
2.4 ns (typical) at V
CC
= 5 V
• Designed for 2.3 V to 5.5 V V
CC
Operation
• Over Voltage Tolerant Inputs
• LVTTL Compatible – Interface Capability With 5 V TTL Logic with
V
CC
= 3 V
• LVCMOS Compatible
• 24 mA Balanced Output Sink and Source Capability
• Near Zero Static Supply Current Substantially Reduces System
Power Requirements
• Replacement for NC7WZ02
• Chip Complexity: FET = 112
Figure 1.
A2
Y2
Figure 1. Pinout Figure 2. Logic Symbol
1
Y1
A1
B2
B1
V
CC
A1
B1
GND
1
2
3
8
7
6
4
5
Y2
Y1
B2
A2
PIN ASSIGNMENT
Pin
1
2
3
4
5
6
7
8
Function
A1
B1
Y2
GND
A2
B2
Y1
V
CC
Input
FUNCTION TABLE
B
L
H
L
H
Output
Y = A + B
Y
H
L
L
L
A
L
L
H
H
http://onsemi.com
See detailed ordering and shipping information in the package
dimensions section on page 4 of this data sheet.
ORDERING INFORMATION
MARKING
DIAGRAM
US8
US SUFFIX
CASE 493–01
8
1
1
8
L3
D
D = Date Code
