NC7WZ132 — TinyLogic
®
UHS Dual 2-Input NAND Gate with Schmitt Trigger Inputs
©2000 Fairchild Semiconductor Corporation www.fairchildsemi.com
NC7WZ132 Rev. 1.11.0
March 2008
NC7WZ132
TinyLogic
®
UHS Dual 2-Input NAND Gate with Schmitt
Trigger Inputs
Features
■
Space saving US8 surface mount package
■
MicroPak™ leadless package
■
Ultra High Speed; t
PD
3.1ns typ. into 50pF at 5V V
CC
■
High Output Drive; ±24mA at 3V V
CC
■
Broad V
CC
Operating Range; 1.65V to 5.5V
■
Matches the performance of LCX when operated at
3.3V V
CC
■
Power down high impedance inputs/output
■
Overvoltage tolerant inputs facilitate 5V to 3V
translation
■
Patented noise/EMI reduction circuitry implemented
■
Schmitt trigger inputs are tolerant of slow changing
input signals
General Description
The NC7WZ132 is a dual 2-Input NAND Gate from
Fairchild's Ultra High Speed Series of TinyLogic
®
. The
device is fabricated with advanced CMOS technology to
achieve ultra high speed with high output drive while
maintaining low static power dissipation over a broad
V
CC
operating range. The device is specified to operate
over the 1.65V to 5.5V V
CC
operating range. The inputs
and output are high impedance when V
CC
is 0V. Inputs
tolerate voltages up to 7V independent of V
CC
operating
voltage. Schmitt trigger inputs achieve typically 1V hys-
teresis between the positive-going and negative-going
input threshold voltage at 5V V
CC
.
Ordering Information
Device also available in Tape and Reel. Specify by appending suffix letter “X” to the ordering number.
All packages are lead free per JEDEC: J-STD-020B standard.
Order
Number
Package
Number
Product Code
Top Mark Package Description Supplied As
NC7WZ132K8X MAB08A WZD2 8-Lead US8, JEDEC MO-187,
Variation CA 3.1mm Wide
3k Units on Tape and
Reel
NC7WZ132L8X MAC08A T5 8-Lead MicroPak, 1.6 mm Wide 5k Units on Tape and
Reel
