© 2000 Fairchild Semiconductor Corporation www.fairchildsemi.com
NC7SZ57 • NC7SZ58 • Rev. 1.0.2
NC7SZ57 / NC7SZ58 — TinyLogic
®
UHS Universal Configuration Two-Input Logic Gates
NC7SZ57 / NC7SZ58
TinyLogic
®
UHS Universal Configurable Two-Input
Logic Gates
Features
Ultra High Speed
Capable of Implementing any Two-Input Logic
Functions
Typical Usage Replaces Two (2) TinyLogic
®
Gate
Devices
Reduces Part Counts in Inventory
Broad V
CC
Operating Range: 1.65V to 5.5V
Power Down High Impedance Input/Output
Over-Voltage Tolerant Inputs Facilitate 5V to 3V
Translation
Proprietary Noise/EMI Reduction Circuitry
Implemented
Description
The NC7SZ57 and NC7SZ58 are universal configurable
two-input logic gates. Each device is capable of being
configured for 1 of 5 unique two-input logic functions.
Any possible two-input combinatorial logic function can
be implemented, as shown in the Function Selection
Table. Device functionality is selected by how the
device is wired at the board level. Figures 4 through 13
illustrate how to connect the NC7SZ57 and NC7SZ58,
respectively, for the desired logic function. All inputs
have been implemented with hysteresis.
The device is fabricated with advanced CMOS
technology to achieve ultra high speed with high output
drive while maintaining low static power dissipation over
a broad V
CC
operating range. The device is specified to
operate over the 1.65V to 5.5V V
CC
operating range.
The input and output are high impedance when V
CC
is
0V. Inputs tolerate voltages up to 5.5V independent of
V
CC
operating range.
Ordering Information
Part Number Top Mark
Eco
Status
Package
Packing
Method
NC7SZ57P6X Z57 RoHS 6-Lead SC70, EIAJ SC-88a, 1.25mm Wide
3000 Units on
Tape & Reel
NC7SZ57L6X KK RoHS 6-Lead Micropak™, 1.0mm Wide
5000 Units on
Tape & Reel
NC7SZ57FHX KK Green 6-Lead, MicroPak2™, 1x1mm Body, .35mm Pitch
NC7SZ58P6X Z58 RoHS 6-Lead SC70, EIAJ SC-88a, 1.25mm Wide
3000 Units on
Tape & Reel
NC7SZ58L6X LL RoHS 6-Lead Micropak™, 1.0mm Wide
5000 Units on
Tape & Reel
NC7SZ58FHX LL Green 6-Lead, MicroPak2™ , 1x1mm Body, .35mm Pitch
For Fairchild’s definition of Eco Status, please visit: http://www.fairchildsemi.com/company/green/rohs_green.html.
