NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com www.RFpassives.com www.SMTmagnetics.com
Surface Mount Aluminum Electrolytic Capacitors
NACZ Series
FEATURES
•
• VERY LOW IMPEDANCE & HIGH RIPPLE CURRENT AT 100KHz
• SUITABLE FOR DC-DC CONVERTER, DC-AC INVERTER, ETC.
• NEW EXPANDED CV RANGE, UP TO 6800μF
• NEW HIGH TEMPERATURE REFLOW "M1" VERSION
• DESIGNED FOR AUTOMATIC MOUNTING AND REFLOW SOLDERING
CHARACTERISTICS
LOW ESR COMPONENT
LIQUID ELECTROLYTE
For Performance Data
see www.LowESR.com
Rated Voltage Rating 6.3 ~ 50Vdc
Rated Capacitance Range
4.7 ~ 6800μF
Operating Temp. Range -55 ~ +105°C
Capacitance Tolerance
±20% (M)
Max. Leakage Current
After 2 Miuntes @ 20°C
0.01CV 0r 3μA, whichever is greater
Tan δ @ 120Hz/20°C
W.V. (Vdc) 6.3 10 16 25 35 50
S.V. (Vdc) 8.0 13 20 32 44 63
φ4 ~ φ6.3mm Dia.
0.24 0.20 0.16 0.14 0.12 0.10
φ8 ~ φ16mm Dia.
C <
1000μF
0.28 0.24 0.20 0.16 0.14 0.14
C = 1500μF
0.29 0.25 0.21 - 0.14 -
C = 2200μF
0.30 0.26 - 0.18 - -
C = 3300μF
0.32 - 0.24 - - -
C = 4700μF
0.34 0.30 ----
C = 6800μF 0.38 -----
Low Temperature
Stability
Impedance Ratio @ 120Hz
W.V. (Vdc) 6.3 10 16 25 35 50
Z-40°C/Z+20°C 322222
Z-55°C/Z+20°C 544333
Load Life Test @ 105°C
4 ~ 6mm Dia. 1,000 hours
8 ~ 12.5mm Dia. 2,000 hours
Capacitance Change Within ±25% of initial measured value
Tan δ
Less than ±200% of the specifi ed maximum value
Leakage Current Less than the specifi ed maximum value
LOW IMPEDANCE
AT HIGH FREQUENCY
INDUSTRY STANDARD
STYLE FOR SWITCHERS
AND CONVERTERS
STANDARD PRODUCT AND CASE SIZE TABLE Dφ x L (mm)
Cap (μF)
Code
Working Voltage (Vdc)
6.3 10 16 25 35 50
4.7 4R7
- - - - 4x6.3 4x6.3
10 100
- - - 4x6.3* 5x6.3* 6.3x6.3*
15 150
- - 4x6.3 6x6.3 5x6.3* -
22 220
- 4x6.3 5x6.3* 5x6.3 5x6.3* 6.3x6.3*
27 270
4x6.3* - ----
33 330
- 5x6.3 - 6.3x6.3 6.3x6.3* 6.3X8*
47 470
5x6.3 - 6.3x6.3 6.3x6.3 6.3x6.3* 6.3x8*
56 560
5x6.3* - - 6.3x6.3 - -
68 680
- 6.3x6.3 6.3x6.3* 6.3x6.3 6.3x8* 8x10.5*
100 101
6.3x6.3* - 6.3x6.3* 6.3x8* 8x10.5 8x10.5*
120 121
- 6.3x6.3 ----
150 151 6.3x6.3 6.3x6.3 6.3x8* 8x10.5*
8x10.5*
10x10.5*
10x8
220 221 6.3x6.3 6.3x8 6.3x8*
8x10.5*
8x10.5 10x10.5
10x8
330 331 6.3x8* 8x10.5
8x10.5*
8x10.5 10x10.5 12.5x14
10x8
390 391
- - - - - 12.5x14
470 471 8x10.5
8x10.5
8x10.5 10x10.5* 12.5x14 16x17
10x8
680 681
8x10.5
- 10x10.5 - 12.5x14 -
10x8*
1000 102
8x10.5* 10x10.5 - 12.5x14 - 16x17
1500 152
10x10.5* - 12.5x14 - 16x17 -
2200 222
- 12.5x14 - 16x17 - -
3300 332
12.5x14 - 16x17 - - -
4700 472
- 16x17 ----
6800 682
16x17 - ----
Denotes New Value
RoHS
Compliant
includes all homogeneous materials
