MPX4115A
Rev 5, 1/2009
Freescale Semiconductor
© Freescale Semiconductor, Inc., 2006-2009. All rights reserved.
Pressure
Media Resistant, Integrated Silicon
Pressure Sensor for Manifold
Absolute Pressure, Altimeter or
Barometer Applications On-Chip
Signal Conditioned, Temperature
Compensated and Calibrated
The MPX4115A series is designed to sense absolute air pressure in
altimeter or barometer (BAP) applications. Freescale's BAP sensor integrates
on-chip, bipolar op amp circuitry and thin film resistor networks to provide a
high level analog output signal and temperature compensation. The small form
factor and high reliability of on-chip integration makes the Freescale BAP
sensor a logical and economical choice for application designers.
Features
• 1.5% Maximum Error Over 0° to 85°C
• Ideally Suited for Microprocessor Interfacing or Microcontroller-Based Systems
• Temperature Compensated Over -40°C to +125°C
• Durable Epoxy Unibody Element or Thermoplastic (PPS) Surface Mount Package
• Available as Standard Fluorosilicone Gel (MPXA4115A, MPX4115A) or Media Resistant Gel (MPXAZ4115A)
ORDERING INFORMATION
Device Name
Package
Options
Case
No.
# of Ports Pressure Type
Device Marking
None Single Dual Gauge Differential Absolute
Unibody Package (MPX4115A Series)
MPX4115A
Tray 867-08
• •
MPX4115A
MPX4115AP
Tray 867B-04
• •
MPX4115AP
MPX4115AS
Tray 867E-03
• •
MPX4115A
Small Outline Package (Media Resistant Gel) (MPXAZ4115A Series)
MPXAZ4115A6U
Rails 482
• •
MPXAZ4115A
MPXAZ4115AC6U
Rails 482A
• •
MPXAZ4115A
MPXAZ4115A6T1
Tape and Reel 482
• •
MPXAZ4115A
Small Outline Package (MPXA4115A Series)
MPXA4115AC6U
Rails 482A
• •
MPXA4115A
MPXA4115AP
Tray 1369-01
• •
MPXA4115AP
MPXA4115A6T1
Tape and Reel 482
• •
MPXA4115A
MPXA4115A6U
Rails 482
• •
MPXA4115A
MPX4115A
INTEGRATED
PRESSURE SENSOR
15 to 115 kPa (2.2 to 16.7 psi)
0.2 to 4.8 V Output
Series
Application Examples
• Altimeter
• Barometer
• Aviation Altimeters
• Industrial Controls
• Engine Control
• Weather Stations and Weather
Reporting Devices
