MPX5050
Rev 11, 03/2010
Freescale Semiconductor
© Freescale Semiconductor, Inc., 2007-2010. All rights reserved.
Pressure
Integrated Silicon Pressure Sensor
On-Chip Signal Conditioned,
Temperature Compensated and
Calibrated
The MPXx5050 series piezoresistive transducer is a state-of-the-art
monolithic silicon pressure sensor designed for a wide range of applications,
but particularly those employing a microcontroller or microprocessor with A/D
inputs. This patented, single element transducer combines advanced
micromachining techniques, thin-film metallization, and bipolar processing to
provide an accurate, high level analog output signal that is proportional to the
applied pressure.
Features
• 2.5% Maximum Error over 0° to 85°C
• Ideally suited for Microprocessor or Microcontroller-Based Systems
• Temperature Compensated Over -40° to +125
°C
• Patented Silicon Shear Stress Strain Gauge
• Durable Epoxy Unibody Element
• Easy-to-Use Chip Carrier Option
ORDERING INFORMATION
Device Name
Case
No.
# of Ports Pressure Type
Device
Marking
None Single Dual Gauge Differential Absolute
Unibody Package (MPX5050 Series)
MPX5050D
867 • • MPX5050D
MPX5050DP
867C • • MPX5050DP
MPX5050GP
867B • • MPX5050GP
MPX5050GP1
867B • • MPX5050GP
Small Outline Package (MPXV5050 Series)
MPXV5050GP
1369 • • MPXV5050GP
MPXV5050DP
1351 • • MPXV5050DP
MPXV5050GC6U
482A • • MPXV5050G
MPXV5050GC6T1
482A • • MPXV5050G
Small Outline Package (Media Resistant Gel) (MPVZ5050 Series)
MPVZ5050GW7U
1560 • • MZ5050GW
MPX5050
Series
0 to 50 kPa (0 to 7.25 psi)
0.2 to 4.7 V Output
MPXV5050
MPVZ5050
