Document Number: MPX2202
Rev 7, 01/2012
Freescale Semiconductor
© 2005-2008, 2012 Freescale Semiconductor, Inc. All rights reserved.
Pressure
200 kPa On-Chip Temperature
Compensated Silicon
Pressure Sensors
The MPX2202 devices series are silicon piezoresistive pressure sensor
providing a highly accurate and linear voltage output directly proportional to
the applied pressure. The sensor is a single monolithic silicon diaphragm with
the strain gauge and a thin-film resistor network integrated on chip. The chip
is laser trimmed for precise span and offset calibration and temperature
compensation. They are designed for use in applications such as pump/
motor controllers, robotics, level indicators, medical diagnostics, pressure
switching, barometers, altimeters, etc.
Features
• Temperature Compensated Over 0°C to +85°C
• Easy-to-Use Chip Carrier Package Options
• Available in Absolute, Differential and Gauge Configurations
• Ratiometric to Supply Voltage
• Available in Easy-to-Use Tape and Reel
ORDERING INFORMATION
Device Name
Case
No.
# of Ports Pressure Type
Device Marking
None Single Dual Gauge Differential Absolute
Unibody Package (MPX2202 Series)
MPX2202A
344
• •
MPX2202A
MPX2202DP
344C
• •
MPX2202DP
MPX2202AP
344B
• •
MPX2202AP
MPX2202GP
344B
• •
MPX2202GP
MPX2202ASX
344F
• •
MPX2202A
Small Outline Package (MPXV2202 Series)
MPXV2202GP
1369
• •
MPXV2202GP
MPXV2202DP
1351
• •
MPXV2202DP
MPXV2202GC6TI
482A
• •
MPXV2202G
MPXV2202GC6U
482A
• •
MPXV2202G
MPAK Package (MPXM2202 Series)
MPXM2202D
1320
• •
MPXM2202D
MPXM2202DT1
1320
• •
MPXM2202D
MPXM2202A
1320
• •
MPXM2202A
MPXM2202GS
1320A
• •
MPXM2202GS
MPXM2202GST1
1320A
• •
MPXM2202GS
MPXM2202AS
1320A
• •
MPXM2202AS
MPX2202
Series
0 to 200 kPa (0 to 29 psi)
40 mV Full Scale
(Typical)
Application Examples
• Pump/Motor Controllers
• Robotics
• Level Indicators
• Medical Diagnostics
• Pressure Switching
• Barometers
• Altimeters
