FRDM-KW41Z RF System Evaluation Report
for 802.15.4 Applications
1. Introduction
This document provides the RF evaluation test results
of FRDM-KW41Z for the 802.15.4 applications
(O-QPSK modulation). It includes the test setup
description and the tools for you to perform the tests on
your own. To get the KW41Z radio parameters, see the
MKW41Z/31Z/21Z Data Sheet (document
MKW41Z512).
For more information about the FRDM-KW41Z
Freedom Development Board, see the FRDM-KW41Z
Freedom Development Board User's Guide (document
FRDMKW41ZUG). Find the schematic and design files
at this link (NXP web page).
NXP Semiconductors
Document Number: AN11999
Application Note
Rev. 0
,
08/2017
Contents
1. Introduction ........................................................................ 1
1.1. List of tests .............................................................. 3
1.2. Software .................................................................. 3
2. Tests summary ................................................................... 4
3. Conducted tests .................................................................. 6
3.1. TX tests ................................................................... 6
3.2. RX tests ................................................................. 20
3.3. Return loss ............................................................ 30
4. Radiated tests ................................................................... 33
4.1. Rx test setup .......................................................... 33
4.2. Rx spurious ........................................................... 34
5. Antenna measurements .................................................... 35
5.1. Return loss ............................................................ 35
6. Conclusion ....................................................................... 36
7. References ........................................................................ 37
8. Revision history ............................................................... 37
