Overview
The Kinetis MCU portfolio consists of multiple pin-, peripheral- and software-compatible MCU
families based on the ARM
®
Cortex™-M4 core. Families are built from innovative 90 nm thin-film
storage (TFS) flash technology with unique FlexMemory (EEPROM) capability, and offer industry-
leading low power and mixed signal analog integration.
The K40 MCU family adds Full-Speed USB 2.0 On-The-Go with device charger detect capability
and a flexible, low-power segment LCD controller with support for up to 320 segments. Devices
start from 64 KB of flash in 64 LQFN packages extending up to 512 KB in a 144 MAPBGA package
with a rich suite of analog, communication, timing and control peripherals.
32-bit MCUs
Low-power MCUs with USB and LCD
Kinetis K40 Family
Target Applications
• GPSreceivers
• Bloodglucosemeters
• Bikecomputers
• Currencycounters
Kinetis K40 Family
Standard Optional
Kinetis K40 Family
Cyclic
Redundancy
Check (CRC)
Xtrinsic
Low-Power
Touch-Sensing
Interface
Segment
LCD Controller
Timers
System Memories
Communication Interface
sH
MI
Clocks
Internal and
External
Watchdogs
Memory
Protection Unit
(MPU)
DMA
Low-Leakage
Wake-Up Unit
Phase-Locked
Loop
Frequency-
Locked Loop
Low/High-
Frequency
Oscillators
Internal
Reference
Clocks
Carrier
Modulator
Transmitter
Periodic
Interrupt
Timers
Independent
Real-Time
Clock (RTC)
Security
and Integrity
Analog
Core
Interrupt
Controller
Debug
Interfaces
DSP
ARM
®
Cortex™-M4
72/100 MHz
16-bit
ADC
PGA
Analog
Comparator
6-bit
DAC
12-bit
DAC
Voltage
Reference
FlexTimer
Programmable
Delay Block
Low-Power
Timer
Program Flash
(64 to 512 KB)
FlexMemory
(32 to 256 KB)
(2 to 4 KB EE)
Serial
Programming
Interface
(EzPort)
SRAM
(16 to 128 KB)
External
Bus Interface
(FlexBus)
GPIOI
2
C
UART
(ISO 7816)
SPI
CAN
I
2
S
Secure
Digital Host
Controller
(SDHC)
USB On-the-Go
(LS/FS)
USB Voltage
Regulator
USB Device
Charger Detect
(DCD)
