Consumer and Industrial Market
i.MX51 Applications Processors
Consumer and industrial portfolio:
i.MX512, i.MX513 and i.MX515
Overview
The i.MX51 family of processors represents
Freescale’s advanced and power-efficient
implementation of the ARM Cortex™-A8 core.
Freescale’s i.MX51 products provide high-
performance processing optimized for the lowest
power consumption for a number of application
spaces where performance and power are critical.
The consumer version of the i.MX51 products are
targeted to run at 800 MHz while the industrial
versions run at 600 MHz. Optimized for low power
consumption, this i.MX offering is part of a growing
family of multimedia-focused products offering
high-performance processing.
Smartbooks/MID, Gaming Devices/
Consoles, Application processors
These i.MX51 processors balance the
performance, power consumption, connectivity
and multimedia capabilities necessary to drive the
latest industrial and consumer products. These
processors are ideal for products that require
advanced user interfaces, sophisticated video
processing, multiple connectivity options and a
high level of system integration. These features
are the building blocks to power the next
great applications.
The i.MX51 family is targeted to drive customer
applications, including smartbooks, mobile
Internet devices, ebooks, digital photo frames,
gaming devices, human machine interface
(HMI) applications, portable navigation devices,
portable medical solutions and many others. With
Freescale’s dynamic voltage and frequency scaling
(DVFS), the same core that runs at 800 MHz can
scale down to 200 MHz at reduced voltage. This
results in significant power reduction for lower
MIPS applications.
Target Applications
• Portablemediaplayers
• Portablenavigationdevices
• Homeappliances
• Graphicalremotecontrols
• Homeautomation
• eBooks
• Digitalpictureframes
• Audioperipheralsandaccessories
• SimpleHMIpanelsfor
industrial applications
Key Features
CPU Complex
• 800MHzARMCortex-A8CPU
• 32KBinstructionanddatacaches
• Unified256KBL2cache
• NEONSIMDmediaaccelerator
• Vectorfloatingpointcoprocessor
System Control
Secure JTAG
Timers
Timer x 3
Memory
ROM 32 KB
PWM x 2
Watch Dog
Security
Sahara v4
TrustZone
®
RTIC
SCC v2
SRTC
RAM 128 KB
Power Mgmt
PLL x 3
Clock Reset
CPU Platform
ARM Cortex™–A8
Vector Floating Point Unit
32 KB
I-Cache
256 KB
L2-Cache
32 KB
D-Cache
ETM
Neon
OpenGL ES 2.0 OpenVG 1.1
eFUSES Smart DMA
i.MX515 Applications Processor
Connectivity
Fast IrDA
HS MMC/
SDIO x 4
CSPI HS x 2/
LS x 1
UART x 3
Multimedia
Image Processing Unit
Hardware Video Codecs
HD720 TV-Out
Resizing and Blending
Inversion and Rotation
Image Enhancement
Camera
1-Wire
ATA-6
USB OTG
HS+PHY
USB HS Host x 3
SPDIF Tx
GPIO
Keypad
Ethernet
Ext Memory I/F
mDDR 200 MHz
DDR2 200 MHz
I
2
C x 3
SSI/I
2
S x 3
