© Freescale Semiconductor, Inc., 2006. All rights reserved.
Freescale Semiconductor
Data Sheet: Technical Data
Freescale reserves the right to change the detail specifications as may be required to permit improvements in the design of its
products.
Document Number: MC9328MXS
Rev. 3, 12/2006
MC9328MXS
Package Information
Plastic Package
Case 1304B-01
(MAPBGA–225)
Ordering Information
See Ta bl e 1 on page 3
MC9328MXS
1 Introduction
The i.MX Family of applications processors provides a
leap in performance with an ARM9™ microprocessor
core and highly integrated system functions. The i.MX
family specifically addresses the requirements of the
personal, portable product market by providing
intelligent integrated peripherals, an advanced processor
core, and power management capabilities.
The MC9328MXS (i.MXS) processor features the
advanced and power-efficient ARM920T™ core that
operates at speeds up to 100 MHz. Integrated modules,
which include a USB device and an LCD controller,
support a suite of peripherals to enhance portable
products. It is packaged in a 225-contact MAPBGA
package. Figure 1 shows the functional block diagram of
the i.MXS processor.
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Signals and Connections . . . . . . . . . . . . . . . 4
3 Electrical Characteristics . . . . . . . . . . . . . . 16
4 Functional Description and Application
Information . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5 Pin-Out and Package Information . . . . . . . . 71
6 Product Documentation . . . . . . . . . . . . . . . . 73
Contact Information . . . . . . . . . . . . . . . Last Page
